| The side-winder tire drive rotary mowers are simply the toughest cutters available today. |
 |
|
| The friction driven power transfer system, with the all new self aligning adjustment mechanism, eliminates gear box, PTO, and slip clutch failures. | ||
 |
Standard safety chains and drive covers . Safety is first with side-winder! | |
| The rugged 200 lb balanced blade carrier stores kinetic energy there by reducing horse power requirements. |
The pneumatic drive tire absorbs the shocks and jolts that other cutters routinely relay to the tractor.
|
 |
 |
||
| Heavy duty tailwheel assembly incorporates roller bearings in the pivot, and is lifetime lubricated. | ||
|
side-winder tire drive specifications |
||
|
htd-6
70" 540 14,250 2 yes 2"- 12" cat 4 friction (tire) front / rear std. 3/16 steel 3/8 steel 1/4 AR 400 1600 lbs |
(heavy tire drive)
cutting width operating rpm blade tip speed (fpm) free swinging blades formed stump jumper cutting height driveline drive type safety chains deck material side skirt material skid shoes approximate weight |
htd-7
81-3/4" 540 16,229 2 yes 2"- 12" cat 4 friction (tire) front / rear std. 3/16 steel 3/8 steel 1/4 AR 400 1800 lbs |
